BNC Series


Mechanical & Environmental : Mating Two stud bayonet coupling Durability 500 matings Coupling Nut Retention 100 lbs min Cable Retention RG-58,141,142,223 →40 lbs min RG-59,62A,210→40 lbs min RG-174,188,316 →20 lbs min RG-179B,187A →20 lbs min Temperature Range -65°C to 165°C Vibration MIL-STD-202 Method 204 Test Cond. B. Salt Spray MIL-STD-202 Method 101 Test Cond. B. Thermal shock MIL-STD-202 Method 107 Test Cond. B. 　 　 　Meaterial : 　 Material Plating Connector Body Brass Nickel or Gold Center Contact Male:Brass Female:Brass, 　　　　Phosphor Bronze or 　　　　Beryllium Copper Gold Gold Insulation Teflon or Delrin None Gasket Silicone Rubber, Rubber None Crimp Ferule Annealed Copper Same as Body

Note: In keeping on going product improvement, we reserve right to make     product changes at any time without notice.  Contact for more info Weltech Electronics E/26-31 , G.I.D.C Industrial Estate, Phase II, Dared, Jamnagar 361 004. Gujarat (INDIA.) Phone :- +91-288-2730034 Fax :- +91-288-2730589 Email :- pnbudh@satyam.net.in  avon@avonconnectors.com
